SWMMVis

Qt6/C++ graphical user interface for the SWMMVis storm-water simulation engine (v6.0.0)

[](LICENSE)

---

Overview

A new GIS-based graphical user interface being developed for SWMM 6.0. The application is built with C++20 and the Qt 6 framework, providing tight integration with the next-generation SWMMVis computational engine.

Key capabilities:

• Interactive map canvas with pan/zoom, CRS reprojection, and layer management (vector, raster, WMS/WMTS, XYZ tiles, SWMM model & results layers)
• SWMM model setup, editing, and validation
• Simulation control and results visualization
• GIS data import/export via GDAL

Dependencies

Dependency	Version	Notes
Qt	6.5+	Widgets, OpenGL, Network, Concurrent, Svg, Charts
GDAL	3.x	GIS/CRS support — installed via vcpkg
openswmm.engine	branch swmm6_rel	Engine — expected at ../openswmm.engine
QPropertyModel	branch dev	Property editor — expected at ../QPropertyModel
vcpkg	2025.03.19	Package manager
CMake	3.21+	Build system

Building

1. Clone sibling repositories

All three repos must be siblings in the same parent directory:

# From the directory that will contain all repos:
git clone -b swmm6_gui  https://github.com/HydroCouple/openswmm.gui.git
git clone -b swmm6_rel  https://github.com/HydroCouple/openswmm.engine.git openswmm.engine
git clone -b dev        https://github.com/cbuahin/QPropertyModel.git QPropertyModel
git clone               https://github.com/microsoft/vcpkg.git

cd vcpkg
./bootstrap-vcpkg.sh   # Windows: bootstrap-vcpkg.bat
cd ..

2. Install Qt 6

Download and install Qt 6.5+ via the Qt Online Installer, then set the QT_ROOT_DIR environment variable to point to the kit directory:

# Linux example
export QT_ROOT_DIR=$HOME/Qt/6.7.0/gcc_64
# macOS example
export QT_ROOT_DIR=$HOME/Qt/6.7.0/macos

3. Configure and build

cd openswmm.gui

# macOS (Release)
cmake --preset=Darwin
cmake --build --preset=Darwin

# Linux (Release)
cmake --preset=Linux
cmake --build --preset=Linux

# Windows (Release) — from a Visual Studio Developer Prompt
cmake --preset=Windows
cmake --build --preset=Windows

Debug builds append -debug to the preset name (e.g., Darwin-debug).

4. Run tests

cmake --preset=Darwin -DSWMMVIS_BUILD_TESTS=ON
cmake --build --preset=Darwin
ctest --test-dir build/darwin -C Release --output-on-failure

API Documentation

Generated with Doxygen and published to GitHub Pages on every push to main/swmm6_gui:

doxygen docs/Doxyfile   # output → docs/html/

Disclaimer

This open-source project is provided on an "as is" basis and the user assumes responsibility for its use.
